EverFlo 5L/min Stationary Oxygen Concentrator

  User Guide




Additional Information

Weight 31 lbs
Dimensions 9.5 × 15 × 23 in

EverFlo 5L/min Stationary Oxygen Concentrator

With OPI and UltraFill Connector Ultra-quiet Stationary Oxygen Concentrator With a sound level of 40 decibels, the new EverFlo Q can significantly reduce noise complaints. Respironics’ compact, 31-pound EverFlo Q is the first ultra-quiet concentrator available at an affordable price. The new EverFlo Q combines the small size, light weight and low maintenance of our popular EverFlo oxygen concentrator, with the added value of an ultra-quiet sound level.  Sound Level: 40 dBA typical

  • Input Voltage: 120 VAC (+/- 10%)
  • Input Frequency: 60 Hz
  • Average Power : 350 Watts
  • Oxygen Concentration* : (at 5 LPM) 93% (+/- 3%)
  • Liter Flow: 0.5-5 liters per minute
  • Weight: 31 lbs (14 kg)
  • Dimensions: 23 in (584 mm) H, 15 in (381 mm) W, 9.5 in (241 mm) D
  • OPI (Oxygen Percentage Indicator) Alarm Levels: Low Oxygen 82%, Very Low Oxygen: 70%
  • Operating Temperature: 55°F to 90°F (12°C to 32°C)
  • Storage/Transport Humidity: -30°F to 160°F (-34°C to 71°C) up to 95% relative humidity
  • Operating Humidity: Up to 95% relative humidity
  • Outlet Pressure: 5.5 PSI
  • Operating Altitude: 0 to 7,500 ft (0 to 2,286 m)
  • Warranty 3 Years


    * Device operation above or outside of the specified voltage, LPM, temperature, humidity and/or altitude values may decrease oxygen concentration levels.

Specs Width: 15 Inches Height: 23 Inches Depth: 9.5 Inches Weight: 31 lbs Sound Level: 40 dBA typical Oxygen Output 0.5-5 liters per minute Oxygen Outlet Pressure: 5.5 PSI Oxygen Concentration: (at 5 LPM) 93% (=/- 3%) Input Voltage: 120 VAC +/- 10% Input Frequency: 60hz Average Power Consumption: 350 Watts Required Maintenance Compressor Intake Filter: Change every 2 years Compressor maintenance: 25,000 hours OPI (Oxygen Percentage Indicator) Alarm Levels: Low Oxygen: 82%, Very Low Oxygen: 70% Operating Temperature: 55 F to 90 F (12 C to 32 C) Storage/Transport Humidity: -30 F to 160 F (-34 C to 71 C) up to 95% Relative Humidity Operating Altitude: 0 to 7,500 ft (0 to 2,286 m) Respironics Warranty: 3 years limited.
